1x16 Opto-Mechanical Switch
Duchy Xu
Contact person
Basic Information
| Place of Origin | Shanghai China (Mainland) |
|---|---|
| Brand Name | BPI |
| Model Number | BPMS-116M |
1x16 Opto-Mechanical SwitchFeatures: Wide Wavelength Range Built-in PositionMonitor Low Insertion Loss Stable and Reliable Performance Applications:Network Monitoring and Switching Fiber Testing Systems Instrument Testing and Measurement Specifications: Parameters1x16UnitWavelength Range 1310 and 1550 (SM)nmInsertion Loss Max.2.6 (Typ.:2.4)dBSwitching Time Max.8msCross Talk Min.55(SM), 35(MM)dBPolarization Dependent Loss Max.0.05dBWavelength Dependent Loss Max.0.25dBRepeatability Max.±0.02dBOptical Return Loss Min..50 (SM), 30(MM)dBOptical Power Handling Max.500mWLife Cycles (Durability) Min.10 MillionstimesOperating Temperature -20 - +70CStorage Temperature -40 - +85CSwitching Voltage 5.0VDimension 179(L)x110(W)x15(H)mm
